Heavy Duty Dismountable Narrow Aisle Racking System With 800-2000kg Capacity

  • Heavy Duty Dismountable Narrow Aisle Racking System With 800-2000kg Capacity
  • Heavy Duty Dismountable Narrow Aisle Racking System With 800-2000kg Capacity
  • Heavy Duty Dismountable Narrow Aisle Racking System With 800-2000kg Capacity
  • Heavy Duty Dismountable Narrow Aisle Racking System With 800-2000kg Capacity
Place of Origin China
Brand Name Qifei
Certification ISO9001；CE；SGS
Model Number Narrow Aisle
Document Product Brochure PDF
Minimum Order Quantity 10
Price 50
Packaging Details Standard Export
Delivery Time 20 days after deposit
Payment Terms 30% deposit, 70% before delivery
Supply Ability 8000ton/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Structure Dismountable Structure Applications Factory， Logistic Cental
Versatility Suitable For Various Pallet Sizes And Weights Length 1000-4000MM, Customized
Weight Capacity As Your Request Accessibility Allows Forklifts To Access Narrow Aisles
Store Pallet Levels 3-10 Levels
Highlight

800kg capacity narrow aisle racking system

,

SGS certified narrow pallet racking

,

dismountable structure narrow pallet racking
Leave a Message
Product Description

Product Description:

Designed to allow forklifts to access narrow aisles with ease, our narrow aisle warehouse racking is perfect for warehouses and storage facilities where space is at a premium.



With a length range of 1000-4000MM, our narrow aisle pallet racking can be customized to fit your specific storage needs.



Our narrow aisle storage racking system is also highly versatile and can accommodate various pallet sizes and weights, making it an excellent choice for businesses that handle a wide range of products. Additionally, the weight capacity of our racking system can be tailored to your specific requirements.



With our Narrow Aisle Storage Racking, you can improve the accessibility and organization of your warehouse, allowing you to maximize your storage space while increasing efficiency and productivity.



So why wait? Invest in our Narrow Aisle Storage Racking today and take your warehouse operations to the next level!

Applications:

This Narrow Aisle Steel Racking is not only versatile, but also durable and reliable. It is certified with ISO9001, CE, and SGS, ensuring that it meets the highest quality standards.



The dismountable structure also allows for easy assembly and disassembly, making it a convenient solution for any warehouse or storage facility.



With aisle widths ranging from 1100-2200mm, this Narrow Aisle Steel Racking is perfect for those who want to optimize their storage capacity. Its narrow design makes it ideal for storing goods in tight spaces, while still allowing for easy access to all products.



This product is suitable for various occasions and scenarios, including those with limited storage space or those looking to increase their storage capacity without expanding their facility.

Customization:

Style Warehouse Storage Pallet Rack
Selection Narrow Aisle Steel Racking
Dimension Standard Pallet:1200*800 / 1200*1000
1100*1100 / 1066*1220
Depth:1000MM / 900MM / 1020MM
Width: 2700MM / 2300MM / 2500MM / 2432MM
Height::pitch is adjusted by increments of 75mm
Customized Pallet:contact us directly
Upright 80*60;
90*60; 90*70; 90*75;
100*67; 100*70; 100*75;
120*75; 120*87mm,
Thickness:1.5~3.0mm
Beam Height:80~160mm;
Width:45mm/50mm;
Thickness:1.5~2.5mm
Bearing Capacity 5000KG per level max ; 1500KG per pallet max
Material Q235B
OEM&ODM Available
Surface Treatment Galvanized/Powder Coating
Color Customized
Sample Available
General Use Warehouse Shelving/Rack, etc.

Support and Services:

The Narrow Aisle Pallet Racking system is designed to optimize warehouse space utilization by reducing aisle width and increasing storage density. Our product technical support and services include:

  • Design and layout planning
  • Installation and assembly assistance
  • Customized solutions to meet specific storage needs
  • Regular maintenance and safety inspections
  • Repair and replacement of damaged components
  • Training and education on proper use and maintenance

Our team of experts is dedicated to ensuring that our customers receive the highest level of support throughout the life of their Narrow Aisle Pallet Racking system.

Packing and Shipping:

Product Name: Narrow Aisle Pallet Racking

Packaging: The product will be securely packed to prevent damage during transportation.

Heavy Duty Dismountable Narrow Aisle Racking System With 800-2000kg Capacity 0

Shipping: We offer nationwide shipping via our trusted logistics partners. Shipping costs will vary based on the location and volume of the order.

Heavy Duty Dismountable Narrow Aisle Racking System With 800-2000kg Capacity 1
